Gavita Pro 1000e DE UK Slimline

Gavita Pro 1000e Slim Line DE UK

Created for grow rooms with low ceilings the professional Gavita Pro 1000e Slim DE UK Lighting fixture is flexible and compact. With no compromise to performance the optimised super efficient ballast measures only 19.4 cm high.


Using the Gavita Repeater Bus Interface the fixture can only be controlled via an external Gavita Master Controller this setup allows you to directly daisy chain 100 fixtures per string and five strings per controller port to connect a maximum of 500 fixtures per controller port!


Making it simply to change your reflector every 1 – 2 years depending on grow room environment the new Gavita Pro 1000e Slim is compatible with PRO M110 DR SR, HR 96 DE and W 150 Reflectors.


The 1000 Watt Gavita 400v Pro-Line ballast features a dial that allows you to change the light output between 600/660/750/825/1000/1150 watts. When using this feature make sure the light has been on for ten minutes or ideally set the desired output before the Gavita comes on.


Gavita Pro 1000e Slim Line DE UK Specifications:
Input Voltage:240 Volt
Input Current:4.42A at 240V
Input Power:1000 Watt
Input Current:4.5 A at 240V
Input Power:1236 Watt
Power Factor:> 0.97 – 0.99
Input Frequency:50 – 60 Hz
Power Inlet: IEC C14,
Power Output settings: 50 – 115%
External control signal: RJ connector built in (6P6C)
Dimensions:22.2” x 9.7” x 7.8” (56.5 x 24.5 x 19.5cm) (height excl. mounting hooks)
Product weight: 8.4 lbs (3,8 kg)
Case Temp. (°C):< 70 °Celsius / 158 °Fahrenheit
Ambient Temp. (°C):0 ~ 35 °Celsius / 32 ~ 95 °Fahrenheit
Reflector Material: HortiStar HR 96 1000 DE in bracket, Miro aluminium

KEY FEATURES

• Gavita Pro 1000e Slim Line DE UK (400V) Features:
• Powerful 1000W 400V Double Ended EL lamps
• External control with Repeater Bus interface
• Light maintenance and highest light output
• System design and concept by Gavita
• Sealed housing (Class I) with Gore-Tex ventilation plug
• Professional UV resistant rubber wiring
• Super passive cooling to prolong electronics lifetime
• Available Mounting brackets for Unistrut/c-profiles
